AIKW50N65DF5 IGBT MODULE 150A 650V
ID:
ID125782
Availability:
Lead time:
to order
Shipping:
Enter shipping destination
SKU:
AIKW50N65DF5NEW
- Product condition: new
- Warranty: 24 MONTHS
- Dedicated courier: yes
AIKW50N65DF5 INFINEON
INFINEON AIKW50N65DF5 we find in the category IGBT modules are devices whose task is to stop or enable the flow of current. Depending on the application, IGBT modules consist of several IGBT transistors and other additional components. These devices are commonly used in inverters, motors, power supplies, controllers and welding machines. IGBT modules are ideal for industrial devices due to the possibility of reducing power losses, ease of control and reliability.Translated with www.DeepL.com/Translator (free version) IGBT modules
Technical data AIKW50N65DF5 INFINEON
| Green | yes |
| Halogen-free | yes |
| Type | IGBT + Diode |
| Technology | IGBT TRENCHSTOP™ 5 |
| Switching Frequency | 15-120 KHz |
| Package | PG-TO247-3 |
| VCE max [V] | 650 |
| ICpuls max [A] | 150 |
| Ptot max [W] | 270 |
| VCE(sat) [V] | 1,66 |
| VCE(sat) max [V] | |
| Eon [mJ] | 0,49 |
| td(on) [ns] | 21 |
| tr [ns] | 12 |
| td(off) [ns] | 156 |
| tf [ns] | 6 |
| QGate [nC] | 108 |
| IF max [A] | 40 |
| VF [V] | 1,54 |
| Qrr [nC] | 680 |
| Irrm [A] | 15,5 |
| IC @ 100° max [A] | 53,5 |
| IC @ 100° [A] | |
| IC @ 25° max [A] | 80 |
| IC @ 25° [A] | |
| Product Family |
Buying at RGB Automatyka gain:
Full device warranty AIKW50N65DF5 INFINEON.
You can be sure of the devices you are buying.
Access to 24/7 support - also on weekends and public holidays.
Our consultants will assist you in choosing the right device, advise you on the installation and maintenance. We are at your disposal all the time.
Express shipping of the model AIKW50N65DF5.
Each of our devices is sent by dedicated courier, following all the rules security.
If you have a defective device AIKW50N65DF5 INFINEON - contact us! We specialize in repairing automation and industrial electronics. We will fix your model SEMiX453GB12E4s even in 24 hours! We guarantee free collection and shipping of the device.For free, we will carry out its diagnosis at specialized test stations, and if you do not decide to repair- you will not incurred any costs. In addition, we provide up to 2 years warranty on all repairs performed.
Dołącz do grona naszych klientów już dziś!
- Weight [kg] 19.0000
- Model AIKW50N65DF5
