Current frequency inverter Altivar 71 allows for a unique range of inverters providing a solution perfectly fit to your needs. High reliability, advanced functions are only the basic features of those products. Thanks to being open for cooperation with all kinds of networks and users, the Altivar 71 inverter has application for such areas like: lines, cranes, woodworking machines, packaging machines, textile machines and other special purposes devices requiring a stable operation in even the most difficult conditions.
Furthermore, the ATV71HD30N4 model offers a lot of useful solutions such as: speed regulation with the use of vector control with or without the graphic terminal for displaying text, configurable function buttons, menu, Power Removal protection feature, in/out expansion card, programmable cards.
Every Altivar 71 inverter has over 150 unique features such as: PID regulator, braking control during translational motion, lifting and winding function, which make them modern devices that can be easily adjusted to the individual needs of your business.
Current frequency | 50/60 Hz |
EAN | 3389118069510 |
Depth [mm] | 266 |
Number of input stages | 3 |
Number of output stages | 3 |
Maximum output frequency [Hz] | 1600 |
Maximum nominal power for quadratic rated load of output voltage [kW] | 30 |
Maximum set power for linear rated load of output voltage [kW] | 30 |
Possible four quadrant operation | Yes |
Line voltage from/to [V] to | 480 |
Line voltage from/to [V] from | 380 |
Output voltage [V] | 400 |
Support of other protocols | No |
Support of AS-Interface Safety at Work protocol | No |
Support of ASI protocol | No |
Support of CAN protocol | No |
Support of Data-Highway protocol | No |
Support of DeviceNet protocol | No |
Support of DeviceNet Safety protocol | No |
Support of EIB protocol | No |
Support of EtherNet/IP protocol | No |
Support of Foundation Fieldbus protocol | No |
Support of INTERBUS protocol | No |
Support of INTERBUS protocol-Safety | No |
Support of LON protocol | No |
Support of MODBUS protocol | No |
Support of PROFIBUS protocol | No |
Support of PROFINET CBA protocol | No |
Support of PROFINET IO protocol | No |
Support of PROFIsafe protocol | No |
Support of SERCOS protocol | No |
Support of SUCONET protocol | No |
Support of SafetyBUS protocol | No |
Support of TCP/IP protocol | No |
Allowed industrial usage | Yes |
Output current [A] | 66 |
Relative symmetrical tolerance of power line frequency [%] | 5 |
Relative symmetrical tolerance of power line voltage [%] | 10 |
Protection level (IP) | IP21 |
Width [mm] | 240 |
Allowed usage in residential and commercial areas | Yes |
Built-in controlling devices for braking intensity | No |
Height [mm] | 550 |
Support element | Yes |
With optic interface | No |
Set power efficiency of output voltage [kW] | 30 |
With PC connector | No |
