ATV71HD45N4 ALTIVAR 71 INVERTER 45kW 3x380/480VAC 94A SCHNEIDER ELECTRIC
ID:
ID19619
Disponibilité:
Délai de mise en œuvre:
sur demande
Livraison:
Vérifier le coût de livraison
Réf.:
ATV71HD45N4NEW
- État de l'appareil : neuf
- Garantie : 24 MOIS
- Coursier spécialisé : oui
ATV71HD45N4 SCHNEIDER ELECTRIC
Current frequency inverter Altivar 71 allows for a unique range of inverters providing a solution perfectly fit to your needs. High reliability, advanced functions are only the basic features of those products. Thanks to being open for cooperation with all kinds of networks and users, the Altivar 71 inverter has application for such areas like: lines, cranes, woodworking machines, packaging machines, textile machines and other special purposes devices requiring a stable operation in even the most difficult conditions.
Furthermore, the ATV71HD45N4 model offers a lot of useful solutions such as: speed regulation with the use of vector control with or without the graphic terminal for displaying text, configurable function buttons, menu, Power Removal protection feature, in/out expansion card, programmable cards.
Every Altivar 71 inverter has over 150 unique features such as: PID regulator, braking control during translational motion, lifting and winding function, which make them modern devices that can be easily adjusted to the individual needs of your business.
Technical data
| Power line frequency | 50/60 Hz |
| EAN | 3389118069534 |
| Depth [mm] | 290 |
| Number of input stages | 3 |
| Number of output stages | 3 |
| Number of Industrial Ethernet hardware connectors | 0 |
| Number of PROFINET hardware connectors | 0 |
| Number of RS232 hardware connectors | 0 |
| Number of RS422 hardware connectors | 0 |
| Number of RS485 hardware connectors | 1 |
| Number of USB hardware connectors | 0 |
| Number of other hardware connectors | 11 |
| Maximum output frequency [Hz] | 500 |
| Maximum nominal power for quadratic rated load of output voltage [kW] | 0 |
| Maximum set power for linear rated load of output voltage [kW] | 0 |
| Possible four quadrant operation | YES |
| Line voltage from/to [V] from | 380 |
| Output voltage [V] | 480 |
| Support of other protocols | YES |
| Support of AS-Interface Safety at Work protocol | NO |
| Support of ASI protocol | NO |
| Support of CAN protocol | YES |
| Support of Data-Highway protocol | NO |
| Support of DeviceNet protocol | YES |
| Support of DeviceNet Safety protocol | NO |
| Support of EIB protocol | NO |
| Support of EtherNet/IP protocol | YES |
| Support of Foundation Fieldbus protocol | NO |
| Support of INTERBUS protocol | YES |
| Support of INTERBUS-Safety protocol | NO |
| Support of LON protocol | NO |
| Support of MODBUS protocol | YES |
| Support of PROFIBUS protocol | YES |
| Support of PROFINET CBA protocol | NO |
| Support of PROFINET IO protocol | NO |
| Support of PROFIsafe protocol | NO |
| Support of SERCOS protocol | NO |
| Support of SUCONET protocol | NO |
| Support of SafetyBUS protocol | NO |
| Support of TCP/IP protocol | NO |
| Allowed industrial usage | YES |
| Output current [A] | 94 |
| Relative symmetrical tolerance of power line frequency [%] | 5 |
| Relative symmetrical tolerance of power line voltage [%] | 10 |
| Protection level (IP) | IP20 |
| Width [mm] | 320 |
| Inverter type | Current Inverter |
| Allowed usage in residential and commercial areas | YES |
| Built-in controlling devices for braking intensity | NO |
| Height [mm] | 630 |
| Support element | YES |
| With optic interface | NO |
| Set power efficiency of output voltage [kW] | 45 |
| With PC connector | YES |
OUR PRODUCTS:
- Brand-new equipment
- Every new piece of equipment is inspected before sale for quality and durability. Because of this you can be sure that you equipment will not suddenly fail, but rather will serve continuously for many years.
- Long warranty
- All used devices devices have 24 months warranty.
- Rapid delivery
- We dispatch the items on the same day. Upon your request we can order dedicated courier to fasten the delivery
RGB AUTOMATYKA MEANS:
- Short lead time
- In emergencies every minute is crucial. Become our client and we will deliver you the order even on the same day.
- On-site service
- Equipment repair is carried out at out site in Wroclaw. We have dozens of professional test stands operated by experienced professionals.
- Thousands of satisfied customers
- Over 7500 clients have bought over 11 thousand pieces of equipment from us. Join our group of satisfied customers today!
Safe delivery
We have already sold over 9000 products!
You no longer have to worry about the damages caused during the transport. We know, how important it is to deliver your product safely. Thanks to long co-operation with UPS, we established unique forms and ways of packing products for the transport.
We use 3 types of packing:
- Wooden chest - designed for servodrives ensures maximum safety with the use of special fixing.
- Instapak - polyurethane filling adjusts to the shape and size of transported device ensuring maximum protection.
- Customized transportation pallets - devices of uncommon shapes, sizes and weght are transported on customized transportation pallets, making the delivery as safe as possible.
Join other happy clients of RGB Elektronika!
- Weight [kg] 44.0000
- Power rate [kW] 45
- Input phases 3
- Modèle ATV71HD45N4
