INPUT AC REACTOR 3x200VAC 33,5A 7,5kW AX-RAI00350335-DE OMRON

ID: ID67956
Availability: Product available on request
Lead time: to order
SKU: AXRAI00350335DE
  • Product condition: new
  • Warranty: 24 MONTHS
  • Dedicated courier: yes
new NEW

Do you need this product?

We will deliver it to you in an express way! Get in touch with us:

24/7 📞 +48 717 186 939

📩 [email protected]

AX-RAI00350335-DE OMRON

Input AC reactors protect inverters from voltage fluctuations. AC input transformers protect power modules installed in the inverters.
Input AC reactors are worth using e.g. in cases of connecting many inverters simultaneously.

  1. Rated current: 33,5 A

  2. Input phases: 3

  3. Power: 7500 W

  4. Input: voltage 200 V

  5. Induction: 0,35 mH

Technical data

Inverter AC Reactor
Voltage Model 3G3MX2-_ Order code
1-Phase
200 VAC
AB002/AB004 AX-RAI02000070-DE
AB007 AX-RAI01700140-DE
AB015 AX-RAI01200200-DE
AB022 AX-RAI00630240-DE
3-Phase
200 VAC
A2002/A2004/A2007 AX-RAI02800080-DE
A2015/A2022/A2037 AX-RAI00880200-DE
A2055/A2075 AX-RAI00350335-DE
A2110/A2150 AX-RAI00180670-DE
3-Phase
400 VAC
A4004/A4007/A4015 AX-RAI07700050-DE
A4022/A4030/A4040 AX-RAI03500100-DE
A4055/A4075 AX-RAI01300170-DE
A4110/A4150 AX-RAI00740335-DE

Measurements

  • Weight [kg] 15.0000
  • Power rate [kW] 7,5
  • Input Voltage [V] 200
  • Input phases 3
  • Model AX-RAI00350335-DE
  • Induction (mH) 0,35
  • Rated current (A) 33,5
