SERVO SC040A SIMPLEX MOTION
- Product condition: new
- Warranty: 24 MONTHS
- Dedicated courier: yes
SC040A SIMPLEX MOTION
Simplex Motion Vision to producent wysokowydajnych zintegrowanych serwomotorów o niewielkich rozmiarach.SC-Serie to kompaktowa seria serwomotorów, zawierająca bezszczotkowy silnik prądu stałego.
Brand-new industrial automation
- 24-month warranty
- High quality, ensuring long and uninterrupted operation
- Attractive prices thanks to direct cooperation with maufacturers
CHOOSE BRAND-NEW PRODUCTS FROM OUR SELECTION!
Mechanical parameters
| Motor specifications | SC040A | |
| Torque | Nominal at 4000 rpm | 280 mNm (30 oz-in) |
| Continuous stall | 280 mNm (30 oz-in) | |
| Peak | 800 mNm (113 oz-in) | |
| Speed | Nominal | 4000 rpm |
| Peak | 6000 rpm | |
| Power (in open air) | Continuous | 120 W |
| Peak | 360 W | |
| Efficiency | Up to | 80% |
| Electrical specifications | ||
| Supply voltage | Min | 8 V |
| Typical | 24 V | |
| Max | 28 V | |
| Supply Current | Idle | 0.05 A |
| Continuous | 4.2 A | |
| Peak | 12.5 A | |
| Mechanical specifications | ||
| Dimensions | Body (L x W x H) | 54 x 42 x 52.5 mm |
| Shaft | D5 x 24 mm | |
| Mounting | Screws in front | 4-M3 |
| Weight | 280 g | |
| Controller specifications | ||
| Integrated incremental encoder solution | Counts per revolution | 4096 |
| Resolution | 0.09º | |
| Protection | overcurrent, torque, voltage, temperature, locked shaft | |
| Interfaces | RS485 / RS232 TTL / Step motor interface / Quadrature encoder / Analog control | |
| Digital Inputs, IN1-4 | Maximum voltage | -0.5..+30V |
| Low/high threshold | Configurable 0..+3.3V | |
| Pull up/down resistor | 10kOhm to +3.3V or GND, or disabled | |
| Digital inputs, IN5-8 | Maximum voltage | -0.5..+8.0V |
| Low/high threshold | Low < 0.7V, high > 2.4V | |
| Pull up resistor | none | |
| Analog inputs, IN1-4 | Maximum voltage | -0.5..+30V |
| Input range | 0..+3.3V | |
| Digital outputs, OUT1-4 | Control | Logic, single pulse, PWM, RC servo control |
| Maximum voltage | -0.5..+30V | |
| Maximum voltage | -0.5..+30V |
