OUTPUT AC REACTOR 3x400VAC 22A 11kW AX-RAO02500220-DE OMRON

Identificación: ID67976
Disponibilidad: El producto está disponible bajo pedido
Tiempo de entrega: a petición
Sku: AXRAO02500220DE
  • Product condition: new
  • Warranty: 24 MESES
  • Dedicated courier: yes
new NUEVO

¿Necesita este producto?

Se lo entregaremos en un abrir y cerrar de ojos. Póngase en contacto con nosotros:

24/7 📞 +48 717 186 939

📩 [email protected]

AX-RAO02500220-DE OMRON

DAC output reactors reduce motor vibrations caused by powering it with the use of inverter.
Sinusoidal filter can be also used in situations when the length of the wire between the inverter and the motor is longer than 10 meters.

  1. Rated current: 22 A

  2. Phases: 3

  3. Power: 1100 W

  4. Input voltage: 400 V

  5. Induction: 2 mH

Technical data

Inverter AC Reactor
Voltage Model 3G3MX2-_ Order code
200 VAC AB001/AB002/AB004/A2001/
A2002/A2004
AX-RAO11500026-DE
AB007/A2007 AX-RAO07600042-DE
AB015/A2015 AX-RAO04100075-DE
AB022/A2022 AX-RAO03000105-DE
A2037 AX-RAO01830160-DE
A2055 AX-RAO01150220-DE
A2075 AX-RAO00950320-DE
A2110 AX-RAO00630430-DE
A2150 AX-RAO00490640-DE
400 VAC A4004/A4007/A4015 AX-RAO16300038-DE
A4022 AX-RAO11800053-DE
A4030/A4040 AX-RAO07300080-DE
A4055 AX-RAO04600110-DE
A4075 AX-RAO03600160-DE
A4110 AX-RAO02500220-DE
A4150 AX-RAO02000320-DE

Measurements

  • Peso [kg] 15.0000
  • Power rate [kW] 1,1
  • Input Voltage [V] 400
  • Input phases 3
  • Modelo AX-RAO02500220-DE
  • Inducción (mH) 2
  • Corriente nominal (A) 22
