Current frequency inverter Altivar 71 allows for a unique range of inverters providing a solution perfectly fit to your needs. High reliability, advanced functions are only the basic features of those products. Thanks to being open for cooperation with all kinds of networks and users, the Altivar 71 inverter has application for such areas like: lines, cranes, woodworking machines, packaging machines, textile machines and other special purposes devices requiring a stable operation in even the most difficult conditions.
Furthermore, the ATV71HU75N4 model offers a lot of useful solutions such as: speed regulation with the use of vector control with or without the graphic terminal for displaying text, configurable function buttons, menu, Power Removal protection feature, in/out expansion card, programmable cards.
Every Altivar 71 inverter has over 150 unique features such as: PID regulator, braking control during translational motion, lifting and winding function, which make them modern devices that can be easily adjusted to the individual needs of your business.
Power line frequency | 50/60 Hz |
EAN | 3389118064638 |
Depth [mm] | 187 |
Number of input stages | 3 |
Number of output stages | 3 |
Number of RS485 hardware connectors | 1 |
Maximum nominal power for quadratic rated load of output voltage [kW] | 7.5000 |
Maximum set power for linear rated load of output voltage [kW] | 7.5000 |
Line voltage from/to [V] to | 480 |
Line voltage from/to [V] from | 380 |
Support of CAN protocol | YES |
Support of MODBUS protocol | YES |
Allowed industrial usage | YES |
Output current [A] | 25 |
Relative symmetrical tolerance of power line frequency [%] | 5 |
Relative symmetrical tolerance of power line voltage [%] | 10 |
Protection level (IP) | IP20 |
Width [mm] | 175 |
Inverter type | Voltage Inverter |
Allowed usage in residential and commercial areas | YES |
Height [mm] | 295 |
Support element | YES |
