3-stage 3x400V power supply and 1-stage 1x230V,
3x400V output and 3x230V output,
Keyboard,
Braking module,
Modbus communication as standard.
Control | Control method | U/f control, Sensorless vector control, | |
Frequency setting resolution | Digital setting resolution: 0.01 Hz, Analog setting resolution: 0.06 Hz for 60 Hz | ||
Frequency setting precision | Digital: 0.01 % max. output frequency, Analog: 0.1 % max. output frequency | ||
U/f characteristics | linear, quadratic, User U/f | ||
Overload possibility | 150% nominal current for 1 minute | ||
Torque boost | Manual or automatic torque boost | ||
Operating | Input signals | Control method | keyboard / Terminal block / RS485 communication / external keyboard |
Frequency setting | Analog: 0 ~ 10V; -10V~10V or 4 ~ 20mA Digital: Keyboard | ||
Start signal | Operating singal forward and backward (NPN/PNP choice) | ||
Stepper operating | Setting up to 8 stepper speeds & 8 acceleration and braking times (0 ~ 6000s.) with the use of multi-function inputs | ||
Emergency stop | Instant cutoff of voltage at inverter output | ||
Master frequency | Primary speed selection at inverter input | ||
Output signals | Operating functions | Frequency detection level, Overload alarm, Getting stuck, Voltage too low and too high, Inverter overheat, Operating, Hold, Constant speed, Inverter by-pass, Speed search, Stepper operating, Sequence operating | |
Error output | Output relay (30A, 30C, 30B) – AC250V 1A, DC30V 1A | ||
Output parameters | Output frequency, Output current, Output voltage, DC bus voltage – one to choose (output: 0 ~ 10V) | ||
Functions | Direct current braking, Limiting frequency, Avoiding frequency, second motor function, slip compensation, protection against change of direction, Autorestart, Inverter By-pass, Autotuning, PID regulator | ||
Protection | Emergency shutdown | Voltage too low and too high, Overload, Open fuse, Ground fault, Inverter overheat, Motor overheat, No output stage, External error, Communication error, Setpoint lost, Hardware error | |
Inverter alarm | Protection against stall, Overload alarm, Temperature sensor error | ||
Autorestart | Possibility of up to 10 autorestart attempts | ||
Keyboard | Displayed values | Output frequency, Output current, Output voltage, Frequency setting, Operating speed, DC bus voltage | |
Displayed errors | Memory and breakdown (up to last 5) errors storaged bythe inverter | ||
Environment | Operating temperature | -10°C ~50°C | |
Storage temperature | -20°C ~65°C | ||
Air temperature | Less than 90%, while operating in 50°C – 30% | ||
Vibrations | Below 1000m below 5,9m/sec ² (=0,6g) |
