Inverters from the ATV312 series are fully compatible both mechanically and configuration-wise with the ATV31 series. All the current inverters from the ATV312 range are highly efficient (up to 30% energy efficiency) despite their compact size. This is achieved thanks to such solutions such as: easier SoMove programming process (free software available from the manufacturer), automatic control optimization and mechanical fit for the motor, integrated EMC filter, possibility of assembling without gaps (no need for resizing).
Furthermore, the ATV312HD11N4 frequency regulator has 6 configurable 24VDC digital inputs (internal or external), 2 N/O and N/C relay outputs with intersection and 1 open N/C, 3 voltage-wise or current-wise configurable analogue inputs, 2 voltage-wise or current-wise configurable analogue outputs.
Durable and reliable operation by ATV312HD11N4 inverter is guaranteed by number of certificates such as: EC/EN 61800-5-1, IEC/EN 61800-3 (environment 1 and 2, C1 do C3 categories), CE, UL, CSA, C-Tick, NOM, GOST.
Current frequency | 50/60 Hz |
EAN | 3606480077555 |
Depth [mm] | 152 |
Number of input stages | 3 |
Number of output stages | 1 |
Number of RS485 hardware connectors | 1 |
Maximum output frequency [Hz] | 500 |
Maximum nominal power for quadratic rated load of output voltage [kW] | 1.1000 |
Maximum set power for linear rated load of output voltage [kW] | 1.1000 |
Line voltage from/to [V] to | 500 |
Line voltage from/to [V] from | 380 |
Support of CAN protocol | Yes |
Support of MODBUS protocol | Yes |
Allowed industrial usage | Yes |
Relative symmetrical tolerance of power line frequency [%] | 5 |
Relative symmetrical tolerance of power line voltage [%] | 10 |
Protection level (IP) | IP20 |
Width [mm] | 107 |
Inverter type | Przemiennik napięciowy |
Allowed usage in residential and commercial areas | Yes |
Built-in controlling devices for braking intensity | Yes |
Height [mm] | 142 |
Support element | Yes |
