ATV312HD11N4 ALTIVAR 312 INVERTER 11kW 3x380-500V 27.7A SCHNEIDER ELECTRIC
ID:
ID1417
Disponibilité:
Délai de mise en œuvre:
sur demande
Livraison:
Vérifier le coût de livraison
Réf.:
ATV312HD11N4NEW
- État de l'appareil : neuf
- Garantie : 24 MOIS
- Coursier spécialisé : oui
ATV312HD11N4 SCHNEIDER ELECTRIC
Inverters from the ATV312 series are fully compatible both mechanically and configuration-wise with the ATV31 series. All the current inverters from the ATV312 range are highly efficient (up to 30% energy efficiency) despite their compact size. This is achieved thanks to such solutions such as: easier SoMove programming process (free software available from the manufacturer), automatic control optimization and mechanical fit for the motor, integrated EMC filter, possibility of assembling without gaps (no need for resizing).
Furthermore, the ATV312HD11N4 frequency regulator has 6 configurable 24VDC digital inputs (internal or external), 2 N/O and N/C relay outputs with intersection and 1 open N/C, 3 voltage-wise or current-wise configurable analogue inputs, 2 voltage-wise or current-wise configurable analogue outputs.
Durable and reliable operation by ATV312HD11N4 inverter is guaranteed by number of certificates such as: EC/EN 61800-5-1, IEC/EN 61800-3 (environment 1 and 2, C1 do C3 categories), CE, UL, CSA, C-Tick, NOM, GOST.
Technical data
| Current frequency | 50/60 Hz |
| EAN | 3606480077555 |
| Depth [mm] | 152 |
| Number of input stages | 3 |
| Number of output stages | 1 |
| Number of RS485 hardware connectors | 1 |
| Maximum output frequency [Hz] | 500 |
| Maximum nominal power for quadratic rated load of output voltage [kW] | 1.1000 |
| Maximum set power for linear rated load of output voltage [kW] | 1.1000 |
| Line voltage from/to [V] to | 500 |
| Line voltage from/to [V] from | 380 |
| Support of CAN protocol | Yes |
| Support of MODBUS protocol | Yes |
| Allowed industrial usage | Yes |
| Relative symmetrical tolerance of power line frequency [%] | 5 |
| Relative symmetrical tolerance of power line voltage [%] | 10 |
| Protection level (IP) | IP20 |
| Width [mm] | 107 |
| Inverter type | Przemiennik napięciowy |
| Allowed usage in residential and commercial areas | Yes |
| Built-in controlling devices for braking intensity | Yes |
| Height [mm] | 142 |
| Support element | Yes |
OUR PRODUCTS:
- Brand-new equipment
- Every new piece of equipment is inspected before sale for quality and durability. Because of this you can be sure that you equipment will not suddenly fail, but rather will serve continuously for many years.
- Long warranty
- All used devices devices have 24 months warranty.
- Rapid delivery
- We dispatch the items on the same day. Upon your request we can order dedicated courier to fasten the delivery
RGB AUTOMATYKA MEANS:
- Short lead time
- In emergencies every minute is crucial. Become our client and we will deliver you the order even on the same day.
- On-site service
- Equipment repair is carried out at out site in Wroclaw. We have dozens of professional test stands operated by experienced professionals.
- Thousands of satisfied customers
- Over 7500 clients have bought over 11 thousand pieces of equipment from us. Join our group of satisfied customers today!
Safe delivery
We have already sold over 9000 products!
You no longer have to worry about the damages caused during the transport. We know, how important it is to deliver your product safely. Thanks to long co-operation with UPS, we established unique forms and ways of packing products for the transport.
We use 3 types of packing:
- Wooden chest - designed for servodrives ensures maximum safety with the use of special fixing.
- Instapak - polyurethane filling adjusts to the shape and size of transported device ensuring maximum protection.
- Customized transportation pallets - devices of uncommon shapes, sizes and weght are transported on customized transportation pallets, making the delivery as safe as possible.
Join other happy clients of RGB Elektronika!
- Weight [kg] 11.0000
- Power rate [kW] 11
- Input phases 3
- Modèle ATV312HD11N4
