3-stage 3x400V power supply,
3x400V output,
Built-in DC choke,
Braking module and a filter (up to 22kW),
For 75kW power the inverter does not have a keyboard as standard.
Model | 0008 | 0015 | 0022 | 0037 | 0055 | 0075 | 0110 | 0150 | 0185 | 0220 | ||
(SV xxxx iS7 – 4) | ||||||||||||
Motor power | HP | 1 | 2 | 3 | 5 | 7.5 | 10 | 15 | 20 | 25 | 30 | |
kW | 0.75 | 1.5 | 2.2 | 3.7 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | ||
Output nominal info | Power [kVA] | 1.9 | 3.0 | 4.5 | 6.1 | 9.1 | 12.2 | 18.3 | 22.9 | 29.7 | 34.3 | |
FLA Current [A] | CT | 2.5 | 4 | 6 | 8 | 12 | 16 | 24 | 30 | 39 | 45 | |
VT | 4 | 6 | 8 | 12 | 16 | 24 | 30 | 39 | 45 | 61 | ||
Frequency | 0 ~ 400 Hz | |||||||||||
Voltage | 3-stage 380 ~ 480 V | |||||||||||
Input nominal info | Voltage | 3-stage 2380 ~ 480 VAC (-15% ~ + 10 %) | ||||||||||
Frequency | 50 ~ 60 Hz (±5 %) | |||||||||||
FLA Current [A] | CT | 4.3 | 7.2 | 10.6 | 15.4 | 21 | 25.8 | 39 | 44 | 57 | 57 | |
VT | 3.5 | 5.3 | 7.3 | 10.8 | 13.8 | 22.5 | 26 | 33 | 40 | 52 |
